The specialist for solid building materials with renewable raw materials.

Expansion plug SX Plus Green

The fischer expansion plug SX Plus Green is produced from at least 50 % renewable raw materials. These are not in competition with agricultural areas for food and feed. Thanks to its 4-way expansion, the fischer SX Plus Green expansion plug is the specialist for solid building materials such as concrete, sand-lime brick and masonry. The special fixing blades ensure pre-fixation of the screw, which means that it does not have to be additionally held in place for overhead applications. This screw fixation allows the user a flexible and comfortable setting process. The flexibel plug edge also prevents the plug from slipping deeper into the drill hole for secure installation.

Produkt varijante

Download of image data

Produkt varijante

24 produkt varijanti

Drill diameter

Min. drill hole depth

Anchor length

Min. bolt penetration

Wood and chipboard screws

Drive

Više rezultata

Pregledano 18 od 24 verzija

Advantages

The SX Plus Green is produced with at least 50 % renewable raw materials.
The 4-way expansion ensures optimum force transmission into the building material and guarantees high holding values in solid and perforated building materials.
The special fixing wings ensure pre-fixation of the screw, leaving both of the user's hands free during the setting process.
The expansion-free plug neck prevents the creation of expansion forces on the material surface whilst screwing in the screw. This helps to prevent damage to tiles and plaster.
The special shape of the plug makes it easy to insert into the drill hole with just a few hammer blows.
The pronounced edge of the plug prevents it from slipping deeper into the drill hole and enables secure installation.

Applications

Lamps
Wardrobes
Motion detectors
Skirting boards
Light wall shelves
Mirror cabinets
Mailboxes
TV consoles
Trellis
Folding shutters
Fire detector

Building materials

Concrete
Solid brick
Solid sand-lime brick
Aerated concrete
Vertically perforated brick
Perforated sand-lime brick
Solid stone of leightweight concrete
Hollow block of leightweight concrete
Natural stone
Hollow brick & concrete ceilings
Solid gypsum boards

Primjenjuju se pojedinosti (građevinski materijali, opterećenja itd.) bilo kojeg dostupnog odobrenja. Dodatne dokumente možete pronaći u Download Center.

Atesti

8C029

Functionality

The SX Plus Green is suitable for pre-positioned and push-through installation.
When the plug is inserted, the fixing wings fold inwards. This locks the screw in place when it is inserted into the plug and prevents it from falling out, which is particularly helpful in overhead applications.
When the screw is tightened, the SX Plus Green expands in four directions and thus anchors itself securely in the building material.
The anti-rotation lock prevents the plug from twisting and allows for easy installation.
Suitable for wood and chipboard screws, as well as stud screws.
The required screw length is given by:
the plug length + fixture thickness + the screw diameter.

Mounting Strip 1 Picture

1 / 5

Mounting Strip 2 Picture

1 / 5

Mounting Strip 3 Picture

1 / 5

Drill diameter ( d₀ )	5 mm
Min. drill hole depth ( h₁ )	35 mm
Anchor length ( l )	25 mm
Min. bolt penetration ( l_E,min )	29 mm
Wood and chipboard screws ( d_s )	3.0 - 4.0 mm
Drive	—
Contents	90 x Expansion plug SX Plus Green 5 x 25
Amount	90 pcs
Packaging	Folding box
GTIN (EAN-Code)	4048962481327

Drill diameter ( d₀ )	5 mm
Min. drill hole depth ( h₁ )	35 mm
Anchor length ( l )	25 mm
Min. bolt penetration	—
Wood and chipboard screws ( d_s )	3.0 - 4.0 mm
Drive	—
Contents	50 x Expansion plug SX Plus Green 5 x 25
Amount	50 pcs
Packaging	Blister card
GTIN (EAN-Code)	4048962481846

Drill diameter ( d₀ )	6 mm
Min. drill hole depth ( h₁ )	40 mm
Anchor length ( l )	30 mm
Min. bolt penetration ( l_E,min )	35 mm
Wood and chipboard screws ( d_s )	4.0 - 5.0 mm
Drive	—
Contents	90 x Expansion plug SX Plus Green 6 x 30
Amount	90 pcs
Packaging	Folding box
GTIN (EAN-Code)	4048962481334

Drill diameter ( d₀ )	6 mm
Min. drill hole depth ( h₁ )	40 mm
Anchor length ( l )	30 mm
Min. bolt penetration	—
Wood and chipboard screws ( d_s )	4.0 - 5.0 mm
Drive	—
Contents	30 x Expansion plug SX Plus Green 6 x 30
Amount	30 pcs
Packaging	Blister card
GTIN (EAN-Code)	4048962481860

Drill diameter ( d₀ )	8 mm
Min. drill hole depth ( h₁ )	50 mm
Anchor length ( l )	40 mm
Min. bolt penetration ( l_E,min )	46 mm
Wood and chipboard screws ( d_s )	4.5 - 6.0 mm
Drive	—
Contents	90 x Expansion plug SX Plus Green 8 x 40
Amount	90 pcs
Packaging	Folding box
GTIN (EAN-Code)	4048962481358
